Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001

Name: Automatic Horizontal Gas Fired Hot Water Boiler High Pressure Steam Boiler ISO9001
Brand: HD Boiler
Price: 1 USD

Buy cheap Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001 product

Brand Name : HD Boiler

Model Number : WNS

Certification : ISO9001,ASME,Grade A,SGS,EN

Place of Origin : China

MOQ : 1Set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 500 Sets / Per Year

Delivery Time : 30 Days

Packaging Details : Seaworthy Packing

Condition : New

Structure : Fire Tube

Fuel Available : Gas-Fired, Oil-Fird, Diesel-Fired

Rated Working Pressure(Mpa) : 1.0-1.25

Evaporation capacity : 1-20t / h

Rated Steam Temperature : 184-193

Surface Treatment : Painted

Operation : Automatic

Typical User : Food and Textile and Hotel and Oil Fired

Placemen : Horizontal Boiler

Contact Now

Fast start WNS OIL(GAS) Fired Steam Hot Water Boiler Small Footprint with ISO9001

Structural features

1, WNS series boiler adopts horizontal three return wet back liner structure is a corrugated furnace, Mainly by the pot shell, furnace, steering smoke room, smoke tube etc.

2, Boiler suitable for light oil, heavy oil, natural oil, liquefied petroleum gas, city gas and other fuels.

The performance advantage

Use the wet liner structure, furnace heating surface wave back, symmetrical layout, effectively reduce the thermal stress, improves the safety and life of the boiler.
Using the thread smoke tube to improve the heat transfer effect of flue pipe.
Boiler heating surface layout reasonable, high thermal efficiency, fast start.
The steam boiler combustion chamber adopts low position, so that the boiler water level safety range is larger, the boiler steam is larger, the steam quality is well guaranteed.
Using the international well-know brand burner and advanced automatic control system, the combustion is more stable, more convenient operation, operation more safety.
Boiler structure is compact, small footprint, fast installation.

Automatic Horizontal Gas Fired Hot Water Boiler , High Pressure Steam Boiler ISO9001

Parameter

Model		WNS 2-1.0-Y,Q	WNS 4-1.25Y,Q	WNS 6-1.25-Y,Q	WNS 8-1.25-Y,Q	WNS 10-1.25-Y,Q	WNS 15-1.25-Y,Q	WNS 20-1.25-Y,Q
Rated evaporation capacity(t/h)		2	4	6	8	10	15	20
Rated working pressure(MPa)		1.0	1.25	1.25	1.25	1.25	1.25	1.25
Rated steam temperature		184	193	193	193	193	193	193
Wear-supply temperature		20	20	60	60	60	104	104
Boiler volume(m3)		3.2	7.4	10.6	11.7	14.4	16.8	21.2
Design efficiency(%)		90	90	90	90	90	90	90
Applicable fuel		Light oil,heavy oil,natura gas,liquified gas and urban coal gas
Extemal size	Lenght A(mm)	5084	6022	7151	7600	8360	9050	9650
	Width B(mm)	2450	2700	2800	3000	3000	4500	5000
	Height H(mm)	2380	2684	2882	3200	3200	5200	5600
Boiler weight (t)		7.2	12.6	17.2	18.6	23.5	36.2	45.5
Diamater of main steam opening(mm)		65	100	125	150	150	200	200
Diameter of safety valve(mm)		40×2	50×2	65×2	65×2	80×2	100×2	100×3
Chimney diamater(mm)		350	450	600	700	750	900	1000

Company Introduction

Established in 1985,Zhangjiagang Hua Dong Boiler Co.,Ltd.(trading as HD Boiler),produces power plant; industrial; waste heat; waste incineration; biomass; organic heat carrier and electric steam boilers. Coupled with a comprehensive range of heating surfaces, HD Boiler brings to the market a unique service including boiler design , fabrication, installation, maintenance and replacement of boiler pressure parts.
